Innovative Pulse-Jet Cleaning Technology in Chity Baghouse Dust Collectors

Chity's pulse-jet baghouse systems feature proprietary reverse airflow technology that delivers 30% stronger cleaning pulses while using 20% less compressed air than conventional systems. Our patented diaphragm valve design ensures precise timing (0.1-0.2 sec/pulse) for effective dust cake removal without filter damage.

1.Smart Pressure Monitoring

Automatic adjustment of pulse interval based on differential pressure (100-150 kPa optimal range)

Prevents over-cleaning (common cause of filter abrasion)

2.Energy-Saving Innovations

Low-pressure cleaning system (0.3-0.5 MPa vs industry standard 0.6 MPa)

Integrated energy recovery from compressed air lines

3.Durable Filter Protection

Anti-wear rings at critical contact points

Venturi ejectors for even air distribution (±5% deviation)

Sticky dust: Pre-coated PTFE membrane filters + heated purge air

Abrasive particles: Multi-layer needled felt with ceramic coating

RFID-enabled filter tracking for predictive replacement

Remote diagnostics via IIoT connectivity

Field tests demonstrate:

✔ 18-month average filter life in cement plants (vs 12-month industry standard)

✔ 99.97% filtration efficiency @ 0.3μm particle size

For customized baghouse cleaning solutions, contact our engineering team for a free system audit and performance optimization report.
